FLUX HEXA Professional 60W CO2 Laser Cutter & Engraver
Does FLUX HEXA work with Lightburn?
FLUX Hexa Laser Cutter is compatible with LightBurn software when used with the FLUX LightBurn Cable.
FLUX HEXA Professional CO₂ Laser Cutter & Engraver
The FLUX HEXA is FLUX’s most powerful desktop CO₂ laser system, designed for users who need higher throughput, deeper cutting capability, and consistent precision across long production runs. Powered by a 60W CO₂ laser tube, HEXA is built to handle demanding engraving and cutting tasks across wood, acrylic, leather, rubber, fabric, glass, stone, and coated metals. Its expanded working area, electric bed lift, and high-speed motion system make it a practical upgrade for workshops, studios, and small-scale production environments.
60W CO₂ Laser Power & Expanded Working Area
HEXA is equipped with a newly developed 60W high-spec CO₂ laser tube, offering higher cutting efficiency and improved optical performance compared to previous FLUX desktop systems. The upgraded optical path uses a 38mm focus lens, allowing for better energy concentration and cleaner results on thicker materials.
- 60W CO₂ laser tube for deeper cuts and faster processing
- Working area of 730 × 410 × 125mm (33% larger than Beambox Pro)
- Additional Z-depth supports thicker materials and fixtures
High-Speed Engraving with Precision Motion Control
Driven by powerful Cortex-M4 control chips, the FLUX HEXA achieves engraving speeds of up to 900mm/s without sacrificing accuracy. This makes it well suited for high-detail raster engraving, batch production, and time-sensitive workflows where efficiency matters.
- Maximum engraving speed up to 900mm/s
- Up to 200% faster engraving than Beambox Pro
- Stable motion system for consistent line quality
Electric Bed Lift, Autofocus & Built-In Cleaning Drawer
HEXA is designed to minimise setup time and manual adjustment. The electric lifting platform combined with built-in autofocus automatically sets the correct working height, helping maintain consistent results across different materials. A built-in cleaning drawer simplifies post-job maintenance without removing the full bed assembly.
- Electric Z-axis platform with automatic focus adjustment
- Reduced setup time for repeat jobs and material changes
- Integrated cleaning drawer for fast debris removal
Connectivity, Safety & Beam Studio Workflow
FLUX HEXA integrates seamlessly into modern workflows with both wired and wireless connectivity options. The included USB Wi-Fi dongle allows direct connection to PCs, smartphones, and tablets. Safety systems are built into every layer of the machine, including lid sensors, temperature monitoring, fire warnings, and a high-powered exhaust system. HEXA is operated using FLUX Beam Studio software, which supports common design formats and integrates easily with professional CAD and graphics tools.
- USB and Wi-Fi connectivity for flexible device control
- Automatic laser shutdown when the lid is opened
- Beam Studio support for SVG, PNG, JPG, DXF, PDF, and AI files
| Tech Specs | Work Area: 730 x 410 x 125 mm Machine Dimensions: 1110 x 670 x 273 mm Weight: 58 kg Voltage: AC 220V Touch Panel: 1024 x 600 LCD I / O: Wi-Fi / Ethernet / USB Laser Spec: 60 W CO2 Laser Laser Moving Speed: 0 ~ 900 mm/s Laser Maximum Material Height: 0 - 20 mm (varies by material) Software Mode: Vector / Graphic (monochrome, grey scale) Software Operating System: Windows / macOS / Linux / Chrome / Safari Software File Type: JPG / PNG / SVG / DXF / AI / PDF Packed Dimensions: 1240 x 800 x 410 mm Packed Weight: 70kg |
|---|
What's In The Box?
- 1x FLUX HEXA (distilled water not included, must be filled before usage)
- 1x Honeycomb Platform
- 1x CO2 Laser Tube (60W)
- 1x Vent Hose (200cm) + Ring clamp
- 1x Wi-Fi
- 1x USB cable
- 1x Laser Cutter Lubricant
- 1x Tape to align the mirror's
- 1x Package with wrench's and extra tool's
- 10x Cone spacers
